即使一路電源發生故障也能供電

輸出：3x5A + 2x10A 12V XLR DC母頭

內建延時開機控制分別啟動電源，預防電壓負荷過重

適用於任何已安裝或移動導播室

雙電源電源供應中心
型號
PD-4A
AC輸入
100~240 VAC (50Hz or 60Hz)
AC input outlet: Two AC inputs & Two Power Switches
DC備用輸出
One DC 12V/25A
supports non-regulated DC 12V output
DC輸出
5
12V±5%, 5A XLR DC Female Jack x3
12V±5%, 10A XLR DC Female Jack x1
(share of two XLR DC Jack)
最大功率
360W
DC超載
DC overload protection, auto-recovery
fuses on each DC output terminal
AC超載
non-recovery fuse on the AC input outlet
LED提示燈
Green LED: Unit under working condition
Red twinkle: AC Input failed
1~4 XLR DC outputs LED indicator
電源輸入自動判別
Selectable of Auto/AC input switch
尺寸
484 x 300 x 49 mm
重量
6.1 kg
電源
AC 100-240 VAC
DC 12V 300W
操作溫度
0~40 °C
附件
1 x PD-4A product
1 x AC CORD
